Before deploying the AED, confirm the emergency by ensuring the patient is unresponsive, not breathing normally, and lacks a pulse. Immediately call emergency medical services and begin manual chest compressions while setting up the device. [1]



Step-by-Step Instructions

1. Turn on the AED

   • Press the green Power Button (located at the bottom-center of the front panel, marked with an I/O symbol).

   • The device will immediately start speaking to guide you. Listen closely to the instructions. [1, 2]

2. Expose the Chest

   • Remove or cut all clothing away from the patient's bare skin.

   • If the chest is wet, quickly wipe it dry. If there is excessive chest hair, shave the areas where pads will be placed. [1]

3. Open and Apply the Pads

   • Pull the green tab located at the bottom of the device to pull out the electrode pad pouch.

   • Tear open the pouch, peel the two adhesive pads from their plastic backing one at a time, and stick them firmly to the skin exactly as illustrated on the icons:

     • Pad 1: Upper right chest (just below the collarbone).

     • Pad 2: Lower left side of the chest (just below the armpit area). [1, 2, 3, 4]

4. Heart Rhythm Assessment (Do Not Touch)

   • The AED will announce "Analyzing heart rhythm, do not touch the patient."

   • Make sure no one is touching or moving the patient during this brief window, as motion can disrupt the reading. [1, 2]

5. Deliver a Shock (If Advised)

   • If a shock is needed: The device will say "Shock advised, stand clear." Ensure nobody is touching the patient, look around, and then:

     • For Semi-Automatic (350P/500P): Press the flashing orange Shock Button (heart symbol with lightning bolt) when prompted.

     • For Fully Automatic (360P): The device will countdown and deliver the shock automatically without requiring a button press.

   • If no shock is needed: The device will say "No shock advised" and prompt you to start CPR. [1, 2, 3]

6. Perform CPR

   • Place overlapping hands directly in the center of the patient's chest and perform continuous compressions.

   • Push down hard and fast, matching your compression speed to the audio metronome ticking sound provided by the AED.

   • The device will pause automatically every 2 minutes to re-analyze the heart rhythm. Repeat the cycle until emergency medical professionals take over. [1, 2]



Important Age & Weight Considerations

• Adults and Children over 8 years old (or over 55 lbs / 25 kg): Use the standard gray cartridge currently installed in the machine.

• Infants and Children 1 to 8 years old (under 55 lbs / 25 kg): Slide out the adult cartridge and insert a pink Pediatric-Pak if one is available nearby. If no specialized child pads are available, use the adult pads anyway rather than delaying care. [1, 2, 3]
